DONGFENG 4.8CBM GARBAGE COMPACTOR TRUCK
DONGFENG 4.8CBM GARBAGE COMPACTOR TRUCK
Product Description
| Item | unit | Parameter | |
| Overall dimension | Length, | mm | 5800 |
| width | mm | 2000 | |
| height | mm | 2100 | |
| Wheelbase | mm | 2700,2950 | |
| Rated load mass: | kg | 3550 | |
| Quality of service | kg | 1000 | |
| Gross mass | Kg | 4500 | |
| Chassis model, category, manufacturer | / | Dongfeng Chassis | |
| Number of passengers | seat | 2 | |
| Engine model, production enterprise | / | Anhui Quanchai power Co., LTDQ23-95E60 | |
| Engine rating | KW | 70kw | |
| Maximum design speed | km/h | 95 | |
| Maximum gradient | / | ≧30% | |
| Approach Angle | o | 27.7 | |
| Departure Angle | o | 19 | |
| Effective volume of garbage body | m³ | 5.0 | |
| Filler hopper volume | m³ | 0.8 | |
| Left sewage tank volume | L | — | |
| Right sewage tank volume | L | 170 | |
| Filler sewage tank capacity | L | 170 | |
| Total volume of sewage tank | L | 340 | |
| Working speed | r/min | 1400 | |
| idling | rpm | 750~800 | |
| Fill a cycle time | s | ≤19 | |
| Feeding cycle time | s | ≤10 | |
| Discharge cycle time | s | ≤45 | |
| Oil pump displacement | ml/r | 32(big pump)/10（smal pump） | |
| Hydraulic tank volume | L | 90 | |
| System pressure | MPa | 16 | |
| Operation mode of force extractor | / | pneumatic | |
| Control mode | / | Automatic, manual | |
1.Product profile
This garbage compactor truck is made of Dongfeng chassis and garbage body, filler, shovel, loading mechanism, hydraulic system, electric control system and other components.
It adopts afterloading bidirectional compression technology, hydraulic and electrical core components to select high-quality components with high working efficiency, high working stability, simple and beautiful appearance.
The control mode and operation mode are humanized, and it is a reliable and simple garbage collection and transfer vehicle.
2.Functional profile
It has many functions such as garbage collection, automatic garbage loading and compaction, garbage transfer and dumping.
3.range of application
It is mainly used for the collection and transfer of barreled, bagged and bulk domestic waste in urban residential areas, communities, large factories and mines, institutions and colleges, and narrow streets in the old city.
A Compactor Garbage Truck, also known as a Refuse Garbage Compactor Truck or Waste Compactor Truck, is a vehicle designed specifically for the collection and compression of waste. A garbage compactor collects garbage from residential, commercial and industrial areas and compresses the garbage into a smaller size for efficient storage and transportation. The compaction process increases the truck's capacity and reduces trips to landfills, which reduces transportation costs and reduces environmental impact.
